Dahua - HAC-HDBW1500EP-0280B-S2 - HDCVI - Dome Kamera
- 5 MP
- 2.8 mm fix lens
- DWDR/2DNR/BLC/HLC
- HD/SD/Multi-format Output (switchable)
- Max. IR Range ~30m
- IP67, DC 12V
Über 30 Jahre ErfahrungÜber
Professionelle Beratung durch unsere Experten
Professioneller Aufbau
3 jahre Garantie und Lebenslang Service
Service Qualitat Nr. 1
- 5 megapixel
- 1/2.7 inch CMOS
- 2.8 mm fixed lens
- Max. IR range ~30m
- Light sensitivity 0.005 lux @ F1.6
- 25 fps @ 5MP (2880 x 1620), 25 fps @ 4MP (2560 x 1440), 25 fps @ 1080p (1920 x 1080)
- HD/SD / multi-format output (1x BNC connector), HDCVI / TVI / AHD / CVBS (format switching with PFM820 controller only for 1080p resolution / HD/SD via OSD menu)
- DWDR, 2DNR / BLC / HLC
- IP67/ IK10, DC 12V
- Material Aluminium
- To use the 5MP HDCVI camera in 16:9 display, the firmware of the XVR must be updated to the following version V4.001.0000001.0.R.200908 or a newer version.
|
DORI (Detect, Observe, Recognize, Identify) |
||||
|
Lens |
Identify |
Recognize |
Observe |
Detect |
|
2,8mm |
6,4m |
12,7m |
25,4m |
63,6m |
- Colour
- White
- Camera technology
- HDCVI
- Camera type
- Dome
- Max Resolution
- 5MP
- Image Sensor
- 1/2,7" CMOS
- Max Aperture
- F1.6
- Minimum Illumination
- 0.005 Lux
- Minimum Illumination (IR on)
- 0 Lux
- IR LED Lighting Distance
- 030 m
- Lens Type
- Fixed lens
- Focal Length
- 2.8 mm
- Angle of View (H)
- 111°
- Angle of View (V)
- 58°
- FPS @ 1080p
- 25 FPS
- FPS @ 4MP
- 25 FPS
- FPS @ 5MP
- 25 FPS
- WDR
- DWDR
- Video Output
- 1x BNC output: HDCVI
- Power Supply
- DC 12V
- Power Consumption
- Max. 3.5W
- Operating Conditions
- -40°C ~ +60°C / Less than 95% RH
- Ingress Protection
- IP67
- Vandal Resistance
- IK10
- Casing
- Aluminium
- Special Feature
- IP67 / IK10 / Multiformat / Multi-language OSD
