ETHERNET
ETH
5 x ETH ports, 10/100/1000 Mbps, supports auto MDI/MDIX crossover
IEEE 802.3 series standards
802.3i, 802.3u, 802.3ab, 802.3x, 802.3az
PERFORMANCE SPECIFICATIONS
Bandwidth (Non-blocking)
10 Gbps
Packer buffer
128 KB
MAC address table size
2K entries
POWER
Connector
4-pin industrial DC power socket
Input voltage range
9 – 30 VDC
PoE (passive)
Possibility to power up through ETH1 ports, not compatible with IEEE802.3af, 802.3at and 802.3bt standards, Mode B, 9 - 30 VDC
Power consumption
< 0.4 W/ < 1.8 W
PHYSICAL INTERFACES
Ethernet
5 x RJ45 ports, 10/100/1000 Mbps
Status LEDs
1 x Power LED, 10 x ETH status LEDs
Power
1 x 4-pin power connector
Other
1 x Grounding screw
PHYSICAL SPECIFICATION
Casing material
Full aluminum housing
Dimensions (W x H x D)
100 x 30 x 85 mm
Weight
227 g
Mounting options
DIN rail, wall mount, flat surface (all require additional kit)
OPERATING ENVIRONMENT
Operating temperature
-40 °C to 75 °C
Operating humidity
10% to 90% non-condensing
Ingress Protection Rating
IP30
REGULATORY & TYPE APPROVALS
Regulatory
CE, UKCA, EAC, UCRF, ANRT, CITC, Kenya, FCC, IC, NOM, RCM, BSMI, CB
EMC EMISSIONS & IMMUNITY
Standards
EN 55032:2015 + A11:2020
EN 61000-3-3:2013 + A1:2019
EN IEC 61000-3-2:2019
EN 55035:2017
ESD
EN 61000-4-2:2009
Radiated Immunity
EN IEC 61000-4-3:2006 + A1:2008 + A2:2010
EFT
EN 61000-4-4:2012
Surge Immunity (AC Mains Power Port)
EN 61000-4-5:2014 + A1:2017
CS
EN 61000-4-6:2014
DIP
EN 61000-4-11:2004 + A1:2017
Standards
IEC 62368-1:2018
EN IEC 62368-1:2020+A11:2020
