ETHERNET
ETH
5 x ETH ports, 10/100/1000 Mbps, supports auto MDI/MDIX crossover
IEEE 802.3 series standards
802.3i, 802.3u, 802.3ab, 802.3x, 802.3az
POE OUT
PoE ports
Port 1- 4
PoE standards
802.3af and 802.3at Alternative B
PoE Max Power per Port (at PSE)
30 W
PoE Power Budget (at PSE)
120 W
PERFORMANCE SPECIFICATIONS
Bandwidth (Non-blocking)
10 Gbps
Packer buffer
128 KB
MAC address table size
2K entries
POWER
Connector
4-pin industrial DC power socket
Input voltage range
7 – 57 VDC
PoE-out input voltage range
44 – 57 VDC
Power consumption
Idle: 2 W / Max (no PoE): 9 W / PoE Max: 129 W
PHYSICAL INTERFACES
Ethernet
5 x RJ45 ports, 10/100/1000 Mbps
Status LEDs
1 x Power LED, 10 x ETH status LEDs
Power
1 x 4-pin power connector
Other
1 x Grounding screw
PHYSICAL SPECIFICATION
Casing material
Full aluminum housing
Dimensions (W x H x D)
115 x 32 x 95 mm
Weight
350 g
Mounting options
DIN rail, wall mount, flat surface (all require additional kit)
OPERATING ENVIRONMENT
Operating temperature
-40 °C to 75 °C
Operating humidity
10% to 90% non-condensing
Ingress Protection Rating
IP30
REGULATORY & TYPE APPROVALS
Regulatory
CE, UKCA, EAC, UCRF, CITC, ANRT, FCC, IC, NOM, Anatel, CB, E-mark
EMC EMISSIONS & IMMUNITY
Standards
EN 55032:2015
EN 55035:2017
EN 301 489-1 V2.2.3
ESD
EN 61000-4-2:2009
Radiated Immunity
EN IEC 61000-4-3:2006 + A1:2008 + A2:2010
EFT
EN 61000-4-4:2012
Surge Immunity (AC Mains Power Port)
EN 61000-4-5:2014
CS
EN 61000-4-6:2014
DIP
EN 61000-4-11:2004
Standards
IEC 62368-1:2018
EN IEC 62368-1:2020+A11:2020
