ETHERNET
ETH
5 x ETH port, 10/100 Mbps, supports auto MDI/MDIX crossover
IEEE 802.3 series standards
802.3i, 802.3u, 802.3x, 802.3az
PERFORMANCE SPECIFICATIONS
Bandwidth (Non-blocking)
1 Gbps
MAC address table size
2K entries
Jumbo frame support
2048 bytes
POWER
Connector
2-pin industrial DC power socket
Input voltage range
9 – 30 VDC
PoE (passive)
Possibility to power up through ETH1 ports, not compatible with IEEE802.3af, 802.3at and 802.3bt standards, Mode B, 9 - 30 VDC
Power consumption
Idle: 0.3 W / Max: 0.9 W
PHYSICAL INTERFACES
Ethernet
5 x RJ45 ports, 10/100 Mbps
Status LEDs
1 x Power LED, 10 x ETH status LEDs
Power
1 x 2-pin industrial DC power socket
PHYSICAL SPECIFICATION
Casing material
Aluminium housing
Dimensions (W x H x D)
113.1 x 27.4 x 80.5 mm
Weight
146.5 g
Mounting options
Integrated DIN rail bracket, wall mount, flat surface (additional kit needed)
OPERATING ENVIRONMENT
Operating temperature
-40 °C to 75 °C
Operating humidity
10% to 90% non-condensing
Ingress Protection Rating
IP30
REGULATORY & TYPE APPROVALS
Regulatory
CE, REACH, RoHS, WEEE, UKCA, FCC, IC, CB, RCM
SAFETY
Standards
EN IEC 62368-1:2020+A11:2020
