Dahua XVR5104C-4KL-I3 XVR 4Chn SMD

- 4 channel Recorder / Lite AI / WizSense

- Supports H.265+/ H.265/ H.264+/ H.264/ AI codec
- Max 64Mbps Incoming Bandwidth
- 4 BNC + 4 IP/ Max 8 channels for IP camera input, each channel up to 8MP
- Record Rate Main stream 4K@7fps / 6MP@10fps / 5MP@12fps / 4MP, 3MP@15fps / 4M-N,1080P, 720P, 960H, D1, CIF @25fps / Substream 960H@15fps / D1, CIF@25fps
- 1x HDMI and 1x VGA simultaneous video output (no Spot Monitor)

- 1x SATA for 10 TB HDD

- 2x USB (2x USB 2.0)

- 1x Audio In / 1x Audio Out (RCA Port)

- DC 12V, 2A

- Coaxial Alarm / Audio / PTZ control
- Supports P2P Function

- Support IoT & POS

- no support for Fisheye dewarp / no support for POS

- AI trough Recorder:

1x chn. Face Detection / Face Recognition; or

1x chn. Perimeter Protection; or

4x chn. SMD

Intelligent video system (IVS), with advanced deep learning algorithms, rule is implemented by the recorder, IVS camera is not necessary, selection is limited by function, not all rules are possible at the same time:

Parameter settings

- Perimeter protection with object filter human, vehicle for rules such as trip wire and area monitoring / for up to 1 channels through the device, each with 10 IVS rules //

AI search via filter human, vehicle

- Face identification with database comparison of defined images; Examination of 8 face images / sec. /

- Facial capture with metadata / attributes for up to 1 channels through the device //

AI Search face identification with up to 8 images simultaneously, search for similarities in percent
AI search facial capture using filters with attributes: age, gender, facial expression, glasses, mask, beard

- SMD Smart Motion Detection for up to 4 channels through the device, for cameras to use without SMD Feature.

Dahua XVR5104C-4KL-I3 XVR 4Chn SMD
