Dahua - TPC-SD2241-B7F8-DW-S2 - Thermal PTZ



- Supports H.265 / H.264 / MJPEG codec
- DWDR, day/night (ICR), 2D NR, 3D NR, BLC, HLC
- Max. IR range ~ 50 m
- Micro SD slot for 256 GB
- 2/1 Alarm In/Out
- 1/1 Audio In/Out
- Audio detection (sounds)
- Supports fire detection with alarm output
- Supports temperature measurement (low temp. -20°C ~ +150°C / high temp. 0°C ~ +550°C), accuracy (+-2°C)
- Up to 12 temperature measurement rules with point / line / range
- Fusion mode with thermal and visible channel
- 18 different colour modes selectable, e.g. white-hot/black-hot/ironcrow/icefire....
- Display of the warmest and coldest point
- Image rotation mode, 0° / 90° / 180° / 270° // Image mirroring
- Private masking with 4 zones
- Power supply with DC 12V, PoE, ePoE
- IP67

- Pan/tilt range: Pan: 0° ~ 360° endless; Tilt: -15° ~ 90°, auto flip 180°

- Scan 5x
- 1x wall bracket PFB305W included in the scope of delivery

- Intelligent Video System (IVS), one selection each possible between:
Visible lens:
     - Perimeter protection by tripwire and area monitoring with filter for people and or vehicles.
     - Phone call detection for the detection of people making phone calls.
Thermal lens:
      - Perimeter protection by tripwire and area monitoring with filter for people and or vehicles.
       - Smoking detection for the detection of people who smoke.
- 1x White Light LED & Siren:
- Active deterrent by white light alarm, sound alarm (4 predefined sounds and import customised sounds).



Human: Detection 559m / Recognition 144m / Identification 72m

Vehicle: Detection 1719m / Recognition 422m / Identification 213m



Perimeter protection Range
People: up to 133m
Vehicles: up to 399m

Heat detection distance
86m
