Dahua - HAC-HFW1200TP-0280B-S6 - HDCVI - Bullet

Seien Sie der Erste, der dieses Produkt bewertet

36,00 €

Verfügbarkeit:

Auf Lager

SKU

CX- 13289

- 2 MP
- 2.8 mm fix lens
- Max. 25fps@1080P
- Max. IR Range ~30m
- DWDR,3DNR,AWB,AGC,BLC,HLC
- HD/SD/Multi-format Output (switchable)
- IP67, DC 12V

IBN Number 6923172593061

Details

- 2 megapixel
- 2.8 mm fixed lens
- 1x IR LED, Max. IR range ~30m
- Light sensitivity colour 0.01 lux @F2.0 / black white 0.001 lux @ F2.0
- 25 fps @ 1080p, 25 fps @ 720p
- DWDR, 3DNR / BLC / HLC
- Built-in microphone (can be deactivated in the OSD menu)
- HD/SD / multi-format output (1x BNC connector), HDCVI / TVI / AHD / CVBS (format switching with PFM820 controller or PFM904 Tester / HD/SD via OSD menu)
- IP67
- DC 12V
- Material metal

DORI (Detect, Observe, Recognize, Identify)
Lens	Identify	Recognize	Observe	Detect
2,8mm	4,4m	8,3m	16,5m	41,4m

Specification

Colour: White
Camera technology: HDCVI
Camera type: Bullet
Max Resolution: 2MP
Image Sensor: 1/2,7" CMOS
Minimum Illumination (Color): 0,01 Lux
Minimum Illumination (B/W): 0.001 Lux
IR Light LED: 030 m
Lens Type: fixed lens
Focal Length: 2,8 mm
Max Aperture: F2.0
Angle of View (H): 102°
Angle of View (V): 60°
FPS @ 720p: 25 FPS
FPS @ 1080p: 25 FPS
WDR: DWDR
Video Output: 1x BNC output: HDCVI
Loudspeaker: No
Siren: No
Microphone: No
Power Supply: DC 12V
Power Consumption: Max. 3,2W
Operating Conditions: -40°C ~ +60°C / Less than 95% RH
Ingress Protection: IP67
Casing: Metall
Special Feature: Starlight / IP67 / Multiformat / Multi-language OSD

Herunterladen

Ihre Download-Datei finden Sie hier. Download: Datenblatt
