Dahua - HAC-HDBW2501RP-Z-DP-S2 - HDCVI - Dome - AC/DC

Seien Sie der Erste, der dieses Produkt bewertet

184,00 €

Verfügbarkeit:

Auf Lager

SKU

CX-12738

- 5 MP/Starlight
- 2,7 ~ 13,5mm motorized lens
- Max. 25fps@5MP(16:9)
- HDCVI/AHD/TVI/CVBS Output
- 120db true WDR, 3DNR, BLC, HLC
- Max. IR length ~30m, Smart IR
- IP67, IK10, DC12V/AC24V

IBN Number 6939554946684

Details

- 5 Megapixel / Starlight
- 2,7 ~ 13.5 mm motorized lens

- Max. IR Range ~30m, Smart IR

- 25fps @ 5MP (2880 x 1620), 25fps @ 4MP (2560 x 1440), 25fps @ 1080p (1920 x 1080)
- 5MP, 4MP, 1080p HDCVI resolution switchable via OSD menu
- Multi-format HDCVI /TVI /AHD /CVBS (only switchable with DIP Switch)
- 8x Privacy Masking with OSD
- 120dB True WDR, 3DNR, BLC, HLC, WDR
- IP67, IK10

- DC 12V or AC 24V

DORI (Detect, Observe, Recognize, Identify)
Lens	Identify	Recognize	Observe	Detect
Wide Angle	6,4m	12,8m	25,6m	64m
Tele Zoom	21m	42m	84m	210m

Specification

Colour: White
Camera technology: HDCVI
Camera type: Dome
Max Resolution: 5MP
Image Sensor: 1/2,7" CMOS
Minimum Illumination: 0.001 Lux
Minimum Illumination (IR on): 0 Lux
IR Light LED: 030 m
Lens Type: motorized
Focal Length: 2.7 - 13.5 mm
Max Aperture: F1.6
Angle of View (H): 113° ~ 31,4°
FPS @ 1080p: 25 FPS
FPS @ 4MP: 25 FPS
FPS @ 5MP: 25 FPS
WDR: 120dB
Video Output: 1x BNC output: HDCVI
Power Supply: DC 12V or AC 24V
Power Consumption: Max. 8.7W
Operating Conditions: -30°C ~ +60°C / Less than 95% RH
Ingress Protection: IP67
Vandal Resistance: IK10
Special Feature: Starlight / 5MP / dual power
